Details
Features & Benefits
- 32 character backlit alphanumeric display
- Sealed pushbutton keypad
- Low voltage operation
- Continuous real-time cycle monitoring
- Continuous cad cell resistance reading
- Continuous AC line voltage readout
- Real-time error notification
- Customizable pre-time (valve-on delay) & post-time (Motor off delay)
- 15 cycle history monitoring
- 5-year warranty
- Customizable lockout service message
Electrical Ratings
Inputs
-
- Voltage: 5 VDC +4%
- Current: 25 mA maximum display current
Environmental Ratings
-
- Storage Ambient Temperature: -22°F to +150°F (-30°C to +65°C)
- Operating Ambient Temperature: 0°F to +150°F (-18°C to +65°C)
- Moisture: 5-85% RH, non-condensing and non-crystallizing
Available Configurations
- 52082U — GeniSys® Contractor Tool
- 52082 — GeniSys® Contractor Tool
- 52074U — GeniSys® Contractor Tool 6-pack with 7505A GeniSys® Control
- 52086U — GeniSys® Contractor Tool 6-pack with 7505A and 7505B GeniSys Controls
- 52514U — GeniSys® Contractor Tool with Mounting Kit
GeniSys® Contractor Tool works with following GeniSys® Oil Burner Primary Safety Controls
Upgrade to microprocessor-based burner and boiler control with 10% fuel savings guaranteed!
The Beckett Aquasmart™ / GeniSys® Combination ...
The Beckett GeniSys® 7580 Oil Burner Control is a 240 VAC primary safety control for Commercial / Industrial pressure washer and other ...
The Beckett GeniSys® 7575 Oil Burner Control is a potted (for high moisture environments) 120 VAC primary safety control for ...
The Beckett GeniSys® 7559 Oil Burner Control is a potted (for high moisture environments) 24 VDC primary safety control for oil burners used on ...
The Beckett GeniSys® 7556 Oil Burner Control is a potted (for high moisture environments) 12 VDC primary safety control for oil burners used on ...
The Beckett GeniSys® 7505 Oil Burner Control is a 120 VAC primary safety control for residential and light commercial oil burners used in ...
The BeckettLink® Pro Contractor Tool
The next generation in contractor tools from Beckett, the BeckettLink® Pro Contractor Tool is an optional accessory that plugs into the Com 1 port of the 7505 GeniSys® Primary Control and allows a technician to monitor the current status, view burner cycle history, and program purge timings directly from a smartphone using the myTechnician™ mobile app.
Downloads & Links
Warnings (prop65)
Warranty
Please note, all warranty claims must be initiated through an authorized Beckett supplier/distributor. Distribution policies will not allow Beckett to directly handle warranty claims with installers and/or consumers.
