Details
Features
-
This igniter is a single post (output) and designed for use only with the approved Beckett gas burners and its factory components.
-
It is rated for continuous duty and for use only with the Beckett 7590 primary control.
-
The Beckett gas igniter is designed to mount on specific applicable burners
-
This igniter is supplied with an integral baseplate that must never be removed from the igniter.
Technical Specifications
-
System Supply: Circuit protection at 20A for the system
-
Input Voltage: 120Vac (102 Vac min. – 132Vac max.)
-
Input Current: 0.2A
-
Output Voltage: 30kV peak
-
Output Current: 20mA RMS
-
Secondary One-end Ground
-
Ambient Operating Temperature: -40 to +150°F
-
Storage Temperature: -40 to +150°F
-
Moisture: 5 to 95% Relative Humidity
Dimensions
Downloads & Links
Instructions
Warnings (prop65)
Warranty
Please note, all warranty claims must be initiated through an authorized Beckett supplier/distributor. Distribution policies will not allow Beckett to directly handle warranty claims with installers and/or consumers.
